Alfra Piccolo 38/50B Magnetic Drill 110V or 240V
The Piccolo 38/50B, single speed heavy duty compact core drilling unit. With self adjusting slide and an extra 86mm of height adjustment available allowing for full length HSS jobber type drills to be used in conjunction with the supplied 13mm keyless 3-jaw chuck. A favourite of hire fleets, this German manufactured tool comes complete with safety strap, guard, coolant unit and high quality transport case. Available in 110V or 240V.
| Model | Alfra 38/50B | |
| Clamping force | kgs | 915 |
| Motor | Watts | 1,100 |
| Speed | rpm | 450 |
| Cutter Capacity | mm | 12 x 38 |
| Cutting Depth | mm | 50 |
| Twist Drill Capacity | mm | 1 – 13 |
| Counter Bore | mm | 10 – 40 |
| Magnet Foot | mm | 70 x 185 |
| Length | mm | 250 |
| Width | mm | 70 |
| Height | mm | 430 |
| Weight | kg | 15 |
Features
- Max Capacity Diameter x Depth Of Cut : 38mm x 50mm
- Weldon Shank : 19mm
- Magnetic Adhesion : 915kgs
- Supplied with:
- Transport Case
- Safety Belt
- Coolant Hose and regulating tap
- Keyless Drill Chuck 1-13mm
- Safety Guard
